Key Specification

5W LED Underground Lamp

Specs of optical	light source	5W pure white LED
	luminous flux? (lm)	280lm
	color temperature CCT(K)	3000±300
	color render index(CRI)	?80
	beam angle 2?1/2	63°
	optical decay rate (%)	<3% within 3000 hours
	service life (Hrs)	?40000Hrs
Specs of electric	input voltage(V)	100 ~ 240 Vac
	frequency scope (Hz)	50/60 Hz
	input current (mA)	70mA (@ 110Vac)
	total consumption (W)	5W
	power factor (PF)	0.65
	starting time (S)	?1.2 S (@ 110Vac)
	withstand voltage	3000Vac/1min
Specs of structure	material	aluminium alloy
	dimension(mm)	D98.5*77mm
	N.W. (kg)	0.25Kg
	proof class (IP)	for indoor use
Other specs	working temperature/humidity	-25°C ~ 50°C,10% ~ 90% R.H.
	storage temperature/humidity	-40°C ~ 85°C,0% ~ 95% R.H.
	certificate	CE  UL  CCC
	environmental protection	RoHS

Product Advantage of 5W LED Underground Lam
p1. High Integrated Luminous Efficiency.
2. High Safety Factor.
3. High power factor,
4. Perfect heat dissipation and long lifespan.
5. Own our independent intellectual property rights.
6. High-class design

Service
OEM&ODM customized services.
Fast Order delivery
Two years warranty.

Factory Advantage
1. Owning a great lab with Millions-valued device.
2. About 80,000 M2 building area.
3. Use COB Technology with inventive patent.
4. Certified by“ISO9001:2000 quality management system” and “ISO14001:2004 environment management system”.
5. Awarded by the E.ON of Grid Access authentication.
