Luxury Fingerprint Scan Lock

Luxury Fingerprint Scan Lock

• Model:L700
• Product Approvals:RoHS,FCC
• Capable:UL
• Brand Name:Probuck
• Brief Description:Fingerprint Lock, excellent design with smooth sliding cover, top security access with fingerprint authorization, never lost or forgot keys again

Key Specification

Featutes & Benefits:

Multiple Access: Fingerprint, Password, Keys, remote Control

Convenience: Open the door by touch of finger, no more keys been lost or forgot and will not lock youself out of home any more.

Easy Operation: Good human design for easy use, easy management for master to add or delete user by individual and no need
change the lock at all.

High Security: Probuck patented advamced fingerprint algorithm Biosure9.0,
High accuracy and fast identify speed less one second
Only the registered user can unlock the door.

Excellent Design: Good apperance and sliding cover design to protect the sensor and keypad;
Digital keys with backlit can be easy use in dark night.

Strong Structure: The multi-point mortise can be double lock by upward pull the handle.
The lock body made by inblock casting for durable use.

Mutiple Alarm Function: Low battery warning, Tamper Alarm, Keypad locked function,
Door not closed completely warning.


Specification:

Item Technical Parameters

Sensor Type----------------------------------------------------------------------------  Optical
Resolution--------------------------------------------------------------------------------  500dpi
Identify time------------------------------------------------------------------------------  ?1S
Matching mode-------------------------------------------------------------------------  1:N
FRR-----------------------------------------------------------------------------------------  ?1%
FAR-----------------------------------------------------------------------------------------  ?0.0001%
Angle of fingerprint---------------------------------------------------------------------  360
Fingerprint capacity-------------------------------------------------------------------  100
Password capacity--------------------------------------------------------------------  10pcs
Static Current----------------------------------------------------------------------------  ?46µA
Dynamic Current------------------------------------------------------------------------  ?200mA
Control system--------------------------------------------------------------------------  Dual-Core & Dual Circuit
Password length------------------------------------------------------------------------  8 digital
Battery life---------------------------------------------------------------------------------  5000times unlock operation
Working voltage--------------------------------------------------------------------------  DC6V
Power supply-----------------------------------------------------------------------------  8pcs AA battery
Emergeny power supply--------------------------------------------------------------  DC 9V
Low voltage warning--------------------------------------------------------------------  4.8V
Working temperature-------------------------------------------------------------------  -10? ~ 55?
Working humidity------------------------------------------------------------------------  10%~90%
Storage temperature--------------------------------------------------------------------  -20? ~ 70?
Handle direction--------------------------------------------------------------------------  Not Reversible
Products Life------------------------------------------------------------------------------  More than 100,000 unlock
Door thickness---------------------------------------------------------------------------  40mm~100mm

Note: The specification shall according to the object, we reserver the right for further improve without notice in advance
