Solar Flashlight

Model:	AS012C
Product Approvals:	ISO9001,CE,ROHS
Brief Description:	Led solar torch various colors are available 8 hours working time CE&ROHS ISO9001 OEM Service is available.

Key Specification

1) Solar panel: 0.7W poly or mono silicon solar panel

Stability and high efficiency photoelectric conversion, the average conversion rate is 15%--17%

Lifetime :25years

2) 3pcs AA rechargeable batteries

Item	Cycles	Charge	Rest	Discharge
Life of Cycle Use (?500 cycles)	60mA×16h	0.1CmA×16h	None	0.25CmA×140min
	150mA×190min	0.25CmA×190min	None	0.25CmA×140min
	150mA×190min	0.25CmA×190min	None	0.25CmA to 6.0V/Cell
	60mA×16h	0.1CmA×16h	1-4h	0.2CmA to 6.0V/Cell
Life Expectancy of Standby Use (20)		3 Years

3) 6pcs super bright white LED

Each LED spec.

Item	Symbol	Max. Rating	Unit
Forward Voltage	VF	3.5	V
Luminous Intensity	IV	800	mcd
Peak Forward Current	IF	80	mA
Power Dissipation	PD	100	mW
Operating Temperature range	Topr	-40~+80
Storage Temperature range	Tstg	-25~+100
Soldering Temperature	Tsod	260

4) Material : ABS project material,anti-UV

5) Charging time:6-8 hours, after fully charged, it can work for 6-8h

6) Over charged and over discharged protection
